LF125H
The A series battery, launched by EVE, is a high – performance lithium – ion battery available in multiple models to meet diverse application needs. With a rated voltage of 3.2 V to 3.7 V and capacity from 5Ah to 22Ah, it offers an energy density of up to 242Wh/kg. This series features excellent cycle stability (1,500 to 4,500 cycles) and high – rate discharge capability (up to 8C), making it ideal for EVs, power tools, and energy storage systems.
The EVE A21 is a prismatic lithium-ion battery with a nominal voltage of 3.22V and a nominal capacity of 154Ah. It has a standard cycle life of 2000 cycles at 1C/1C and can discharge at a maximum rate of 5C (25℃ to 60℃). The battery weighs 2755±30 grams, has an energy density of 180Wh/kg, and dimensions of 33.7mm x 346.4mm x 110.0mm.
Advantages of DC180-B Dual Motor Controller
-
The battery can be applied to power generation and energy storage, construction machinery, and various types of vehicles, ships, and trains.
-
LFP material: Olivine structure, stable material structure. Strong P-O covalent bonds form (PO4)3- phosphate ions, making oxygen atoms difficult to escape and ensuring lattice stability and material safety.
-
LFP material: Olivine structure, stable material structure. Strong P-O covalent bonds form (PO4)3- phosphate ions, making oxygen atoms difficult to escape and ensuring lattice stability and material safety.
Technical Specifications
| Power Battery Model: | LF125H |
| Voltage: | 3.22 V |
| Capacity: | 125 Ah |
| Standard Cycle Life: | 4000 times |
| Maximum Discharge Rate: | 3C |
| Weight: | 2310±69 gram |
| Energy Density: | 174 Wh/kg |
| Size: | 47.7mm x 200.7mm x 115.0mm. |
| Lead Time: | 15-30 Working Days |
| Payment Terms: | T/T ,L/C |
| Main Parameters | ||||
| Power Battery Model: | LF125H | Voltage: | 3.22 V | |
| Capacity: | 125 Ah | Standard Cycle Life: | 4000 times | |
| Maximum Discharge Rate: | 3C | Weight: | 2310±69 gram | |
| Energy Density | 174 Wh/kg | Size: | 47.7mm x 200.7mm x 115.0mm. | |
| —–END—– | ||||
Can Quality be Guaranteed?
(1) Rich production experience: We have many years of experience in producing this product, which can match various types of mechanical equipment from 2T to 10T.
(2) Quality management system: Our company has a complete quality management system to ensure that every link meets strict quality standards.
(3) Continuous improvement and feedback mechanism: We focus on continuous improvement, communicate with customers through feedback mechanism, continuously optimize product quality and performance, and ensure that the needs of the market and customers are met.
Is the Price Reasonable?
We are the original manufacturer and can give you the most suitable price. The key to dealing with Chinese suppliers is to find and choose reliable business partners who will not deceive you for short-term business, but aim to establish a long-term career and lifelong partnership. EMAC is one of the reliable partners. We will not pursue short-term high profits, but we care about our decades of good reputation. Our cooperation with all business partners is not only as suppliers and customers, but also as close friends and brothers.
What should I do if I don’t Understand the Product?
You can unconditionally explain your needs to us. We have a professional team that uses simple and clear language to explain the characteristics and advantages of the product and help you choose the right motor to match the best controller. If you need further support or explanation, we are always available to help and explain the relevant content to help you solve the problem.
How to Place an Order?
You can confirm the product by connecting with our sales, or you can choose to contact us through wahtspp or your email, and we will guide you to complete the order process.
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
