Sanci Dual Motor Controller

Sanci has built a series of product platforms from single control, dual control, all-in-one, frequency conversion and explosion-proof with the idea of ​​integrated system design and development (mechanical structure/motor electromagnetic/thermal management/algorithm and control strategy), and can provide more than 20 drive motor controllers according to customer needs, covering all models of new energy commercial vehicles, trucks, special vehicles, construction machinery, rubber-wheeled vehicles, etc. on the market.
In order to better serve customers, Zhejiang CRRC Shangchi has also taken a variety of measures to optimize the layout of the service network and convenient parts supply, which greatly speeds up the service response speed. No matter what product you need, we will provide you with the most satisfactory product.

Advantages of Motor Controllers

Integration and lightweight: Integrating multiple functional modules into one reduces the number of components and connection lines, making the entire system structure more compact, smaller and lighter. For example, the all-in-one controller integrates motor control, DC/DC conversion, OBC and other functions. Compared with the decentralized layout, it greatly reduces the weight of the vehicle and saves the layout space in the vehicle, which is conducive to improving the vehicle’s cruising range and space utilization.
High efficiency: Through optimized design and advanced control algorithms, these controllers can improve the driving efficiency of the motor, so that the motor can maintain a high efficiency under different working conditions. For example, the dual-motor controller can expand the system’s high-efficiency zone and improve the overall efficiency by reasonably allocating the working modes of the two motors;
High reliability: It adopts advanced hardware and software design, has redundant design and self-monitoring functions, and can detect and correct potential faults in time.

Find Motor Controllers by Series

This is a list of all series of motor controllers.
Click here to find dual motor controller by type .

DA500 Dual Motor Controller

DA500 Dual Motor Controller

EMC:Class3
Weight:25 kg
Peak efficiency:98.5 %
Levels of Protection:IP68
Maximum Output Frequency:800 Hz
Dimension(L * W * H):445 * 530 * 168 mm

DA500 Dual Motor Controller

DA360 Dual Motor Controller

EMC:Class3
Weight:25 kg
Peak efficiency:98.5 %
Levels of Protection:IP68
Maximum Output Frequency:800 Hz
Dimension(L * W * H):445 * 530 * 168 mm

DA500 Dual Motor Controller

DA220 Dual Motor Controller

EMC:Class3
Weight:25 kg
Peak efficiency:98.5 %
Levels of Protection:IP68
Maximum Output Frequency:800 Hz
Dimension(L * W * H):445 * 530 * 168 mm

DC180-B Dual Motor Controller

DC180-B Dual Motor Controller

Rated input voltage:450-720 VDC
Peak output voltage:380 Vac
Rated current:108 A
Peak point current:175 A
Peak efficiency:98.9 %
Dimension(L * W * H):459 * 310 * 113 mm

DC180-B Dual Motor Controller

DC180-A Dual Motor Controller

Rated input voltage:250-420 VDC
Peak output voltage:237 Vac
Rated current:120-200 A
Peak point current:270-400 A
Peak efficiency:98.9 %
Dimension(L * W * H):459 * 310 * 113 mm

SA360 Single Motor Controller

SA360 Single Motor Controller

EMC:Class3
Weight:5 kg
Peak efficiency:99.1 %
Levels of Protection:IP68
Maximum Output Frequency:800 Hz
Dimension(L * W * H):278 * 245 * 90 mm

SA150 Single Motor Controller

SA150 Single Motor Controller

EMC:Class3
Weight:12 kg
Peak efficiency:98.9 %
Levels of Protection:IP68
Maximum Output Frequency:800 Hz
Dimension(L * W * H):438 * 317 * 138 mm

SA360 Single Motor Controller

SA500 Single Motor Controller

EMC:Class3
Weight:5 kg
Peak efficiency:99.1 %
Levels of Protection:IP68
Maximum Output Frequency:800 Hz
Dimension(L * W * H):278 * 245 * 90 mm

SA360 Single Motor Controller

SA220 Single Motor Controller

EMC:Class3
Weight:5 kg
Peak efficiency:99.1 %
Levels of Protection:IP68
Maximum Output Frequency:800 Hz
Dimension(L * W * H):278 * 245 * 90 mm

SA360 Single Motor Controller

SA50 Single Motor Controller

EMC:Class3
Weight:5 kg
Peak efficiency:99.1 %
Levels of Protection:IP68
Maximum Output Frequency:800 Hz
Dimension(L * W * H):278 * 245 * 90 mm

DC-DC

DC-DC

Rated input voltage:400-750 VDC
Power rating:33/5 kW @ 24 V
Rated current:110/180 A
Peak point current:175 A
Main drive rated current:160/205/260 A
Dimension(L * W * H):474 * 352 * 198 mm

DC-DC

PDU

Rated input voltage:450-750 VDC
Power rating:3/5 kW @ 24 V
Rated current:110/180 A
Peak point current:175 A
Main drive rated current:160/205/260 A
Dimension(L * W * H):474 * 352 * 198 mm

DC-DC

Gas Pump DC-AC

Rated input voltage:450-750 VDC
Power rating: 5.5 kW
Rated current:13 A
Peak point current:175 A
Main drive rated current:160/205/260 A
Dimension(L * W * H):474 * 352 * 198 mm

DC-DC

Oil Pump DC-AC

Rated input voltage:450-750 VDC
Power rating: 5.5 kW
Rated current:13 A
Peak point current:175 A
Main drive rated current:160/205/260 A
Dimension(L * W * H):474 * 352 * 198 mm

DC-DC

Main Drive

Rated input voltage:450-750 VDC
Power rating:3/5 kW @ 24 V
Rated current:110/180 A
Peak point current:175 A
Main drive rated current:160/205/260 A
Dimension(L * W * H):474 * 352 * 198 mm

Sanci M15 Main Drive Multi-in-one

Sanci M15 Main Drive Multi-in-one

Input Voltage Range: DC 450 V-750 V
Output Voltage: 27.5 VDC
DCDC Power Rating: 3/5 kW @ 24 V
DCDC Rated Current: 110/180 A
Main Drive Rated Current: 160/205/260 A

M04 Auxliary Drive Multi-in-one

M04 Auxliary Drive Multi-in-one

Input Voltage Range: DC 250 V-750 V
Output Voltage: 27.5 VDC
DCDC Power Rating: 3/5 kW @ 24 V
DCAC Power Rating: 5.5 kW
DCDC Rated Current: 110/180 A
