Brock BJ5044TYHEV-H1 Road Maintenance Truck
BJ5044TYHEV-H1 pure electric road maintenance truck is a new generation of multi-functional cleaning truck with zero emission, low noise and intelligent control cleaning operation, which is built by our company according to the market demand, by focusing on the user’s use functions, habits and vehicle operating conditions. The cleaning car is a new type of cleaning urban pavement, non-motorized lanes, stalls oil road surface and urban psoriasis, at the same time suitable for garden medicated multi-functional road cleaning and maintenance car. The car is developed from SAIC Datong SH1047PCEVNZ type two pure electric vehicle chassis, and equipped with high pressure washer system, water tank cleaning, box assembly, front spray frame and fixed cleaning device, electrical system, high pressure waterway and coil device, auxiliary cleaning cart and other components. The car has beautiful appearance, comfortable driving, simple operation, flexible mobility, convenient maintenance, low noise, high reliability, large battery capacity, zero emissions, can be widely used in urban sidewalk, non-motorized lane cleaning and road cleaning.
Advantages of BJ5044TYHEV-H1
-
Water tank volume of 2.5 cubic meters, high pressure pump water flow is consistent, water tank operation time is longer.
-
The chassis chosen is the Datong pure electric chassis, which has a vertical front section and better cab space and visual field.
-
Water consumption is only 1/6 of the ordinary sprinkler, save water, reduce fuel consumption and improve operating efficiency.
-
The high pressure water pump in the high pressure waterway system is driven by the chassis power battery through the inverter and the pump motor. The high pressure water pump adopts the high pressure three plunger pump, which has the characteristics of compact structure, light weight, small size, high outlet pressure and long service life.
Technical Specifications
| Truck Model: | BJ5044TYHEV-H1 |
| Total Mass: | 4495 kg |
| Equipment Weight: | 2750 kg |
| Engine Model: | TZ249XSC7BY001 |
| Rated Load: | 1615 kg |
| Max.Gradeability: | 30 ° |
| Basic Turck(L * W * H): | 5520 mm * 1900 mm * 2250 mm |
| Max. Approach Angle: | 11 ° |
| Max. Departure Angle: | 22 ° |
| Min.Turning Diameter: | 12.5 m |
| Braking Distance: | ≤10 m |
| Max.Vehicle Speed: | 90 km/h |
| Lead Time: | 15-30 Working Days |
| Payment Terms: | T/T ,L/C |
Model |
Total Mass |
Rated Load |
Minimum Ground Clearance |
| BJ5032TYHE6-H1 | 3495 kg | 1375/1465 kg | 190 mm |
| BJ5032TYHE6-P1 | 3495 kg | 1465 kg | 190 mm |
| BJ5044TYHEV-H1 | 4495 kg | 1615 kg | 190 mm |
| BJ5045TYHEV-H1 | 4495 kg | 1155 kg | 150 mm |
| ——END—— | |||
Foton Brock BJ5044TYHEV-H1 Road Maintenance Truck Data Sheet |
|||||
| Model | BJ5044TYHEV-H1 | Min. Ground Clearance | 190 mm | ||
| Total Weight | 4495 kg | Equipment Weight | 2750 kg | ||
| Rated Load | 1615 kg | Truck Length | 5470 mm | Truck Width | 1740 mm |
| Truck Height | 2265 mm | Max. Approach Angle | 11 ° | Max. Departure Angle | 22 ° |
Chassis Argument of Foton Brock BJ5044TYHEV-H1 Road Maintenance Truck |
|||||
| Braking Distance [Full Load 30 km/h] | ≤10 m | Max.Vehicle Speed [Full Load] | 90 km/h | ||
| Model Specifications | SH1047PCEVNZ | Max.Gradeability | 30 ° | Min. Turning Diameter | 12.5 m |
| Motor Model | TZ249XSC7BY001 | Rated Power | 40 kW | Peak Power | 75 kW |
| ——END—— | |||||
Coming Soon
Foton Brock BJ5044TYHEV-H1 Road Maintenance Truck Bodywork Parameter |
|||||
| Max.Cleaning Width | 1.5 m | Cleaning Width of the Front Spray Bar | 1.5 m | ||
| Auxiliary Cleaning Trolley Cleaning Width | 1.5 m | Water Hose Reel Hose Length | 15 m | ||
| Front Spray Boom Deflection Angle | ±20 ° | Volume of the Tank | 2.5 m³ | ||
| ——END—— | |||||
Coming Soon
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
